Description
Ideal for sheet to sheet applications where welding and bolting is not possible. During installation the head forms a secure fixing whilst maintaining an aesthetic and low profile finish. The aluminium body ensures consistent performance and an enhanced resistance to corrosion.
| Collar Ø (mm) |
14 |
| Collar Thickness (mm) |
2.5 |
| Corrosion Rating (1-5) |
3 - Urban & industrial areas (low salt atmosphere) |
| DIN |
DIN 7337 |
| Drill Hole Ø (mm) |
4.9 |
| Finish |
Zinc & Clear Cr3 |
| Head L (mm) |
16 |
| Head Ø (mm) |
4.8 |
| Head Ø x L (mm) |
4.8 x 16 |
| Head Type |
Flange |
| Mandrel L (mm) |
27 |
| Mandrel Ø (mm) |
2.7 |
| Material |
Aluminium |
| Max. Grip Range (mm) |
12 |
| Min. Grip Range (mm) |
10 |
| Substrates |
Steel, Aluminium, Hard Plastic, PVCu |
