Boresite heavy duty plasterboard wall fixings are designed to provide a secure mounting solution for heavy items without the need for additional support. Each fixing is engineered to hold up to 35 kgs of weight, ensuring reliable performance.
• Hold up to 35kgs per wall fixing
• Designed for 12.5mm plasterboards
• For stud walls with 15mm cavity
• Simple drill free installation
• Patented design to maximise load to cost
• Made with engineering PA6 polymer
Instructions
1️⃣ Mark a screw hole and cutting slot on the wall using the included marking template
2️⃣ Cut a 3mm thick slot with a drywall saw or utility knife where marked
3️⃣ Straighten Section B until at 90° to Section A and the band is under tension
4️ Insert into the drywall slot until Section A makes contact with the wall
5️ Mount your hook or bracket to the wall using the included screws
Please Note:
Boresite works by spreading the load over a large surface area of Plasterboard and relies on the screw engaging through the hole in Section B. It is the user’s responsibility to ensure proper engagement by following good installation practice. The manufacturer or Frank's Fasteners is not responsible for damage, destruction or loss of property or belongings due to incorrect installation.
